VEVOR Wire Rope Crimping Tool User Manual

Models: FSH-Y10, NKGS10

Warning!

1. Disconnect the wiring power supply before working.
2. Inspect before every use; do not use if damaged.
3. Keep away from children.

Product overview

This product includes with a wire rope crimping pliers and a cutting pliers. The wire rope crimping pliers is a hand-operated tool used to join wire rope.
The cutting pliers are accessories for crimping pliers are used to cut wire rope.

Product parameters

1. Name: Wire Rope Crimping Pliers
2. Model: FSH-Y10+NKGS10
3. N.W.: 0.86kg
4. G.W.: 0.92kg
5. Package Size: 295x140x40mm

Product structure

Wire rope crimping pliers are mainly made up of the following parts:

1. Crimping block: used to compress and fix the wire rope.
2. Cutting blade: used to cut wire rope quickly
3. Anti-skid handle: Used to operate the manual wire rope crimping pliers.
4. Lock button: used to lock and unlock the tools.

The cutting pliers are mainly composed of the following parts:

• Cutting mouth: used to cut wire rope.
• Handle: Used to operate the cutter.

User Guide

• Determine the diameter of the wire rope to be connected and select the corresponding crimping block.

• Insert the wire rope into the correct place and place crimp blocks on both ends of the wire rope.
• Use the handle to operate the wire rope crimping pliers, and press the crimping block against the wire rope.
• Use cutting pliers to cut off the wire rope, paying attention to safety when cutting to avoid injury.
• Check the connection to make sure it is secure. If something goes wrong, redo the crimping process.

Safety and Maintenance

• Manual wire rope crimping pliers can only be used to join wire rope, not for other materials.
• You must pay attention to safety when using manual wire rope crimping pliers to prevent accidents.
• When using manual wire rope crimping pliers, it is necessary to ensure that it is in normal working condition and stop using them immediately if any abnormal situation occurs.
• Clean manual wire rope crimpers promptly after use to keep dust and debris out.
• Manual wire rope crimping pliers should not be stored in a humid environment for a long time to prevent rust.
