Electric Motor Standard Motor 3 Phase 400v B3 0.12kw 50 Hz Tefc F Insulation

Electric Motor Standard Motor 3 Phase 400v B3 0.12kw 50 Hz Tefc F Insulation

Available: In Stock
Product SKU: DJYS56-2-0.12KWB3V7
$51.99 USD


Features & Details



  • [STANDARD ELECTRIC MOTOR]- The compact and small-sized motor features output 1/6 HP, and three-phase, easy to carry; the rated speed: 2760 RPM to be with high working efficiency, shaft diameter: 9 x 20 mm, service factor: 1, insulation class: F.
  • [ALUMINUM CONSTRUCTION]- The induction motor shell is made of aluminum. The robust and reliable aluminum material can well protect the motor, the appearance is great, and the frame is stable, which can protect the internal circuit from thermal overload.
  • [HIGH SPEED COOLING FAN]- Big fan at one end cools the motor in hours' running, even in dusty or damp environments, reducing energy costs or overheads, reducing the running temperature, increasing winding lifetimes.
  • [PROTECTIVE & STABLE]- The standard motor adopts an IP55 protection rating, which can prevent harmful dust accumulation, completely prevent the engine from being touched, and wash with water without any harm. Even in a high-temperature space, it can continue to run stably.
  • [MULTIPLE APPLICATION]- The electric motors are commonly used in industrial and agricultural production, commercial and household appliances, and other fields, such as hoists/winches, pulley drives, fans, compressors, pump drives, conveyor drives.


Powerful Motor


The high-power motor has a three-phase motor and 230/400V voltage, which can save energy in a long time, reduce energy costs or overhead. Move effortlessly.


High Performance


The electric motor runs at 1/6 HP, and the maximum speed is 2760 RPM, Synchronous speed: 3000 RPM, high hardness shaft is more durable.


Sturdy & Durable Construction


The motor housing is made of durable metal material, robust and reliable, with strength and durability, corrosion resistance, and the surface provides comfortable use.


Fully Enclosed Fan


Even in dusty or damp environments, the big fan at one end cools the motor in hours' running to reduce the energy costs and the running temperature.


IP55 Protection


The electric motor features a high level of waterproof and dustproof, and can be used outdoors, even in a high-temperature space, it can continue to operate stably.


Wide Application


The electric motor is suitable for air compressors, medical equipment refiners, metal cutting machine tools, pumps, fans, transport machinery mixers, food machinery, etc.

0.12 KW 3000 RPM Standard Three Phase Electric Motor

The listing is about three-phase electric motor 0.12 KW 3000 RPM standard motor B3 foot mount. These three-phase electric motors are designed, manufactured, and tested to meet the latest European and international standards and give maximum operating performance and reliability.

  • Standard Electric Motor
  • Aluminum Construction
  • High-Speed Cooling Fan
  • Protective & Stable
Package Content:
Specifications
  • Voltage: 230/400V
  • Frequency: 50 Hz
  • Current: 0.6/0.35A
  • Power: 0.12 kw
  • Phase: 3 Phase
  • HP: 1/6 HP
  • Rated speed: 2760 rpm
  • Synchronous speed: 3000 rpm
  • Shaft diameter: 9 x 20 mm
  • Machine base: 56
  • Mount type: B3 foot mount
  • Service factor: 1
  • Insulation class: F
  • Protection class: IP55

Package Contents

  • 1 x Electric Motor


Features & Details



  • [STANDARD ELECTRIC MOTOR]- The compact and small-sized motor features output 1/6 HP, and three-phase, easy to carry; the rated speed: 2760 RPM to be with high working efficiency, shaft diameter: 9 x 20 mm, service factor: 1, insulation class: F.
  • [ALUMINUM CONSTRUCTION]- The induction motor shell is made of aluminum. The robust and reliable aluminum material can well protect the motor, the appearance is great, and the frame is stable, which can protect the internal circuit from thermal overload.
  • [HIGH SPEED COOLING FAN]- Big fan at one end cools the motor in hours' running, even in dusty or damp environments, reducing energy costs or overheads, reducing the running temperature, increasing winding lifetimes.
  • [PROTECTIVE & STABLE]- The standard motor adopts an IP55 protection rating, which can prevent harmful dust accumulation, completely prevent the engine from being touched, and wash with water without any harm. Even in a high-temperature space, it can continue to run stably.
  • [MULTIPLE APPLICATION]- The electric motors are commonly used in industrial and agricultural production, commercial and household appliances, and other fields, such as hoists/winches, pulley drives, fans, compressors, pump drives, conveyor drives.


Powerful Motor


The high-power motor has a three-phase motor and 230/400V voltage, which can save energy in a long time, reduce energy costs or overhead. Move effortlessly.


High Performance


The electric motor runs at 1/6 HP, and the maximum speed is 2760 RPM, Synchronous speed: 3000 RPM, high hardness shaft is more durable.


Sturdy & Durable Construction


The motor housing is made of durable metal material, robust and reliable, with strength and durability, corrosion resistance, and the surface provides comfortable use.


Fully Enclosed Fan


Even in dusty or damp environments, the big fan at one end cools the motor in hours' running to reduce the energy costs and the running temperature.


IP55 Protection


The electric motor features a high level of waterproof and dustproof, and can be used outdoors, even in a high-temperature space, it can continue to operate stably.


Wide Application


The electric motor is suitable for air compressors, medical equipment refiners, metal cutting machine tools, pumps, fans, transport machinery mixers, food machinery, etc.

0.12 KW 3000 RPM Standard Three Phase Electric Motor

The listing is about three-phase electric motor 0.12 KW 3000 RPM standard motor B3 foot mount. These three-phase electric motors are designed, manufactured, and tested to meet the latest European and international standards and give maximum operating performance and reliability.

  • Standard Electric Motor
  • Aluminum Construction
  • High-Speed Cooling Fan
  • Protective & Stable
Package Content: Specifications
  • Voltage: 230/400V
  • Frequency: 50 Hz
  • Current: 0.6/0.35A
  • Power: 0.12 kw
  • Phase: 3 Phase
  • HP: 1/6 HP
  • Rated speed: 2760 rpm
  • Synchronous speed: 3000 rpm
  • Shaft diameter: 9 x 20 mm
  • Machine base: 56
  • Mount type: B3 foot mount
  • Service factor: 1
  • Insulation class: F
  • Protection class: IP55

Package Contents

  • 1 x Electric Motor
