Illustration on function parameters
2. Temperature error correction F1: When the display temperature and actual temperature are different, this parameter can be corrected to make the two identical, F1 = actual temperature - display temperature.
3. When the temperature sensor meets “Measuring temperature = set temperature – return difference temperature F2, the red indicator is on which means an automatic access to the heating device; When the temperature sensors meets “measuring temperature = set temperature," the red heat indicator is off and the yellow ready indicate light is on which means the heating device is cut off.
4. Digital temperature controller: It is on the control panel and mainly in charge of controlling the heating temperature of the heat pipe to ensure the water temperature inside the tank.
Cleaning and Maintenance
1). In case of accidents, cut off electricity when cleaning the machine
2). Every time after use, clean the machine with a wet towel. Don’t use erosive detergent. Pay special attention when cleaning operation panel, since if water is let inside, electric parts will be damaged and there will be short circuit
3). Do not wash the machine directly with running water
4). Water must be drained out of the tank after it is cooled down
Note
Adjust the temperature to 70-80℃ / 158-176℉ until the chocolate melts, then adjust the temperature according to your own needs.
- Under very careful, long-term research
- Digital control renders the temperature more accurate and scientific
- Water-barrier heating design, easy temperature control, effectively avoiding chocolate scorch in the bottom of the chamber
- Chocolate can be more evenly melted
- With our humanized design concept
- Very easy to operate since it has exhaust steam and drainage system
- Made of best grade stainless steel, type 304#, corrosion resistance and easy to clean
- The temperture is between 30-80℃ / 86-176℉, satify different personal needs without damaging the ingredients of chocolate
- Automatic temperture control system ( automatically stop heating when the temperature is lower than setting, and vice versa)
- Suitable for heating chocolate, cream and milk
- Can also be applied to candles and soaps
- Type: C2002-3
- Condition: New
- Brand: Vevor
- Power: 1500 W
- Voltage: 110 V 50 HZ
- capacity: 12kg
- Machine size: 65 x 36 x 18cm / 25.59" x 14.17" x 7.09"
- Package size: 72 x 43 x 26cm / 28.35" x 16.93" x 10.27"
- Net weight: 10kg / 22.05lbs
- Gross weight: 13kg / 28.66lbs
- Warranty: 2 years
- 1 XC2002-3 Electric Water Heating Chocolate Melter
Illustration on function parameters
1. Return difference temperature F2: F2 = set temperature – lower limit temperature, assuming that the temperature should be controlled between 20 ℃ and 22 ℃, set temperature as 22 ℃, the lower limit temperature as 20 ℃, then the return difference temperature F2 = 2 ℃ (default return difference as 2 ℃).2. Temperature error correction F1: When the display temperature and actual temperature are different, this parameter can be corrected to make the two identical, F1 = actual temperature - display temperature.
3. When the temperature sensor meets “Measuring temperature = set temperature – return difference temperature F2, the red indicator is on which means an automatic access to the heating device; When the temperature sensors meets “measuring temperature = set temperature," the red heat indicator is off and the yellow ready indicate light is on which means the heating device is cut off.
4. Digital temperature controller: It is on the control panel and mainly in charge of controlling the heating temperature of the heat pipe to ensure the water temperature inside the tank.
Cleaning and Maintenance
1). In case of accidents, cut off electricity when cleaning the machine
2). Every time after use, clean the machine with a wet towel. Don’t use erosive detergent. Pay special attention when cleaning operation panel, since if water is let inside, electric parts will be damaged and there will be short circuit
3). Do not wash the machine directly with running water
4). Water must be drained out of the tank after it is cooled down
Note
Adjust the temperature to 70-80℃ / 158-176℉ until the chocolate melts, then adjust the temperature according to your own needs.
- Under very careful, long-term research
- Digital control renders the temperature more accurate and scientific
- Water-barrier heating design, easy temperature control, effectively avoiding chocolate scorch in the bottom of the chamber
- Chocolate can be more evenly melted
- With our humanized design concept
- Very easy to operate since it has exhaust steam and drainage system
- Made of best grade stainless steel, type 304#, corrosion resistance and easy to clean
- The temperture is between 30-80℃ / 86-176℉, satify different personal needs without damaging the ingredients of chocolate
- Automatic temperture control system ( automatically stop heating when the temperature is lower than setting, and vice versa)
- Suitable for heating chocolate, cream and milk
- Can also be applied to candles and soaps
- Type: C2002-3
- Condition: New
- Brand: Vevor
- Power: 1500 W
- Voltage: 110 V 50 HZ
- capacity: 12kg
- Machine size: 65 x 36 x 18cm / 25.59" x 14.17" x 7.09"
- Package size: 72 x 43 x 26cm / 28.35" x 16.93" x 10.27"
- Net weight: 10kg / 22.05lbs
- Gross weight: 13kg / 28.66lbs
- Warranty: 2 years
- 1 XC2002-3 Electric Water Heating Chocolate Melter
