220kg Vertical Pneumatic Punch Press Machine 110v Mute Operation 16mm Die Hole
Pneumatic punch press machine, powered with compressed air, is of high efficiency and easy operation. Suitable for manual operation integration and automated assembly line application.
Advantages:
- No noise in hydraulic system or under standby status.
- Output pressure easy adjustable.
- High accuracy rotational resistance guide rod and guide plate.
- Saves electricity consumption and lowers production cost.
Application:
- Suitable for electronics, electrical appliances, instruments, meters, cameras, watches, jewelry, hardware, clothing, shoes and hats industries, etc...
-
Can
realize cut, punch, blank, moulding, curving and riveting procedures to
sheets, strips and coiled materials. Suitable for processing
non-ferrous metals and plastic articles.
| Operation Pressure | Theoretic Pressure | |||
| Mpa | kg/cm² | psi | N | kg |
| 0.4 | 4 | 110 | 1121 | 114 |
| 0.5 | 5 | 120 | 1402 | 143 |
| 0.6 | 6 | 130 | 1682 | 172 |
| 0.7 | 7 | 140 | 1962 | 200 |
Note:
- The actual output is about 80% theoretical output.
- PNEUMATIC PUNCH - Powered by compressed air and equipped with foot pedal, this punch press is of easy operation and high efficiency, thus reducing labor
- HIGH PERFORMANCE - No noise in hydraulic system or under standby status. This will save electricity consumption and lower production cost
- AIR PRESSURE - Operation pressure easy adjustable from 0.4-0.7 Mpa according to requirement
- HIGH ACCURACY - Equipped with high accuracy rotational resistance guide rod and guide plate, will adapt to high speed precision impact load
- APPLICATION - Suitable for electronics, electrical appliances, instruments, meters, cameras, watches, jewelry, hardware, clothing, shoes and hats industries, etc...
- Voltage: 110V AC
- Power Source: Pneumatic
- Operation Pressure: 0.4-0.7 Mpa (4-7 kg/cm², or 110-140 psi)
-
Theoretical Output Pressure: 1121N-1962N (114-200 kg)
- Actual Output: About 80% theoretical output
- Die Hole Diameter: 16 mm (0.63")
- Depth of Throat and Mouth: 135 x 150 mm (5.3" x 5.9")
- Stroke: 150 x 135 mm (5.9" x 5.3")
- Tracheal Size: 8 x 5 mm (0.31" x 0.2")
- Adjustable Cylinder Size: 63 x 75 mm (2.5" x 2.95")
- Control Form: Manual
- Layout Form: Vertical
- Gross Weight: 39.3 lb (17.8 kg)
- Package Dimensions: 26.4"x13.4"x13.4" (67x34x34cm)
- 1 X Pneumatic Punch Press Machine 110V
- 1 X Foot Pedal
- 1 X Manual
