1/2 Hp Electric Motor 1 Ph 1750rpm 5/8”shaft Keyed Shaft Agricultural Waterproof

1/2 Hp Electric Motor 1 Ph 1750rpm 5/8”shaft Keyed Shaft Agricultural Waterproof

Available: Out of Stock
Product SKU: DJ141256000000001V6
$134.99 USD
Successful pre-order.Thanks for contacting us!
0.5 Hp Electric Motor
The electric motor 141256 is an electrical machine that converts electrical energy into mechanical energy. The SHDC electric motor is commonly used to match water pumps, agricultural machinery, and general equipment. A 115/230 volt electric motor that turns at 1800 RPM. A single-phase motor that has a rigid base and 5/8 inch keyed shaft.
  • Working Efficiency
  • High Speed Cooling Fan
  • Steel Housing
  • Multiple Application
MobileBulletPoint
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
  • Premium Tough Quality
  • Incredibly Low Prices
  • Fast & Secure Delivery
  • 30-Day Returns
  • 24/7 Attentive Service
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
  • Premium Tough Quality
  • Incredibly Low Prices
  • Fast & Secure Delivery
  • 30-Day Returns
  • 24/7 Attentive Service
Powerful Motor
The high-power motor has a single-phase motor and 115/230V voltage, which can save energy in a long time. Reduce energy costs or overhead. Move effortlessly.
High Performance
The electric motor 56 frame runs at 0.5 hp, and the maximum speed is 1800 rpm. Voltage: 115 / 230V 60HZ, high hardness shaft is more durable.
Fully Enclosed Fan
The fan cools the motor during operation, has excellent heat dissipation performance, and prolongs the machine life.
Sturdy & Durable Construction
The motor housing is made of durable metal material, robust and reliable, with strength and durability.
Mounting Bracket Included
A robust mounting bracket is included in the package to improve the motor's stability and reduce friction. Ball-bearing systems are also suitable for many applications.
Wide Application
0.5 hp electric motor is suitable for air compressors, medical equipment refiners, metal cutting machine tools, pumps, fans, transport machinery mixers, food machinery, etc.
Specifications
  • Product: Electric Motor
  • Model: 141256
  • Horsepower: 0.5 HP
  • RPM: 1800 RPM
  • Frame: 56 Frame
  • Voltage: 115/230 V
  • Frequency: 60 Hz
  • Full load amps: 8.8/4.4 A
  • Shaft diameter: 5/8 inch Keyed shaft
  • Shaft length: 1.875 inch
  • Phase: Single phase
  • Service factor: 1.15
  • Enclosure: TEFC
  • Insulation class: B
  • Package size(L x W x H): 40 x 27 x 27 cm/15.75 x 10.63 x 10.63 inch
  • Gross weight: 14.7 kg/32.41 lbs
  • Mounting Type: Rigid
  • IP Rating: IP 55
  • Reversible/Non-Reversible: Reversible
  • AC Motor Type: Induction Motor
