Machinery Skate Dolly User Manual

Warning:

1. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating.
2. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury

GENERAL SAFETY RULES

1. It is recommended to use this product on flat, hard ground.
2. Using this product on uneven or soft ground is strictly prohibited and may cause property and personal injury.
3. This product is unsuitable for use on sloping ground; otherwise, accidents will occur easily.
4. Do not use more than the product load capacity.
5. Because the ground is not smooth, the wheels of each mover may not be all involved in the work; it is recommended to use a nominal load under these conditions.
6. This product should be moved slowly at an allowable speed, as excessive speed can easily cause the mover to slide out. Accidents happen easily.
7. When the load is lighter, the mover’s steering performance is good; conversely, it is not good. Do not swerve when the operator is struggling to turn. Heavy-duty steering will cause severe wear on PU wheels. Jack lifting is recommended to assist the mover in steering.
8. Do not recommend using a single or two movers together to carry large equipment; such use is unsafe. For heavy equipment, 3 or 4 movers are usually used together.
9. Due to the high center of gravity, mover handling measures are required to prevent possible overturning for high and narrow equipment.
10. When multiple movers are used together, rubber pads are added to ensure consistency in height.  When handling, the direction of each mover should be consistent; otherwise, it is difficult or impossible to move. When turning, it is suggested that the weight be lifted slightly with the aid of Jack and other tools to facilitate the mover’s turning.

SAVE THESE INSTRUCTIONS

Machinery Skate Dolly Models and Paramaters

STRUCTURE DIAGRAM

COMPONENTS

Machinery Skate Dolly Maintenance Operation

1. Use a large pry bar or hydraulic jack to lift the equipment.
2. Place the industrial machinery movers at the bottom of the skate dolly.
3. Ensure that the equipment is placed in the load-bearing center of the industrial machinery mover.
4. This product should be moved slowly at an allowable speed, as excessive speed can easily cause the movers to slide out.

NOTE: According to the different weights and sizes of the equipment, to choose the industrial machinery mover model, there are five styles to choose from, as shown below:

2 Steering Modes For Reference:

Machinery Skate Dolly Maintenance

1. After using the mover, remove the wheel of iron filings and other sharp objects, and store it in a dry environment.
2. Regularly inspect the mover. Replace the bearings if the wheel rotation is not flexible, there is ample bearing clearance, or there is noise; replace the wheel in time if it is damaged.
3. After use, the PU Wheel’s mover should be cleaned promptly because sharp objects such as iron filings, sand, oil, etc., can easily hurt the wheel.
4. If the mover’s surface paint is damaged, it should be repaired promptly to avoid rusting.
