VEVOR Car Side Awning User Manual

Models: ATSA1420, ATSA2025

Specifications

Car Side Awning Components

Follow the easy assembly instructions in this manual, and follow the setup and safety guidelines closely.

Inspections: During trips, regularly check that all nuts and bolts attaching your awning to your vehicle are tight and in good repair.

Important Safety Warnings

• Do not attempt to set up the awning in windy conditions.
• All guy ropes must be appropriately attached to the awning and pegged to the ground.
• Guy ropes are trip hazards in the day and night.
• Keep all flame and heat sources away from the awning materials. Under no circumstances should any naked flame sources, fuel-burning devices, or heating devices be used under or near the awning.
• Keep campfires well away from the awning.
• Look for any airborne burning embers that may come into contact with the awning.
• Keep a fire extinguisher or water bucket nearby.
• Do not smoke within the awning. Keep the exit clear.

Fitting Guide

Options for mounting your awning are outlined below.

When mounting the awning, it is important to ensure it is positioned to allow sufficient clearance for the vehicle doors to open.

VEVOR Car Side Awning Installation

For Rooftop Rack

NOTE: You can install option A or B according to your requirement.

For Rooftop Basket

Note: You can choose to install option A or B according to your requirement.

For Cross Bar

Drilling might be needed. Note: If the crossbar does not have holes, the holes must be drilled before installing the bracket.

Note: Partial DIY might be needed due to the different fittings of rooftop rack models. Not all provided parts are necessary for installation; some are backups for different models.

Car Side Awning Setup

Setup Procedure

1. Clean only with cold water and a soft brush: do not use soap or detergent.
2. Do not expose to petrol, oil, or solvents
3. Avoid creases and seams when rolling up the awning.
